50BYJZ 减速永磁步进电动机
典型应用场景：空调风门调节，小型云台，安放监控器，智能洁具，投影仪镜头调节，发电机节气门，自动门锁
重量：220g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
起动频率
|
起动转矩 Pull in Torque kgf.cm(at 300PPS)
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Pull in Rates（PPS）
|
齿轮减速比i
|
Dielectric Stength
|
Class of insulation
|
|
1:15
|
1:22
|
1:33
|
1:122
|
|
50BYJZ26-30
|
12
|
2
|
30
|
2-1-2
|
7.5/i
|
450
|
1.2
|
1.8
|
2.5
|
15
|
500V AC 1Min
|
E
|
|
50BYJZ46-30
|
12
|
4
|
30
|
4-1-2
|
7.5/i
|
350
|
0.8
|
1.2
|
1.8
|
8
|
500V AC 1Min
|
E
|
|
50BYJZ212-30
|
12
|
2
|
30
|
2-1-2
|
3.75/i
|
500
|
2.2
|
3
|
4.5
|
12
|
500V AC 1Min
|
E
|
|
50BYJZ412-30
|
12
|
4
|
30
|
4-1-2
|
3.75/i
|
400
|
1.8
|
2.2
|
3.8
|
11
|
500V AC 1Min
|
E
|
|
|
