50BYJ 减速永磁步进电动机
典型应用场景：监控云台，麻将机，过胶机，投幕机，阀门控制，广告灯箱，自动烧烤炉
重量：220g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
起动频率
|
起动转矩 Pull in Torque kgf.cm(at 300PPS)
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Pull in Rates（PPS）
|
齿轮减速比i
|
Dielectric Stength
|
Class of insulation
|
|
1:501
|
1:336
|
1:247
|
1:202
|
1:125
|
1:100
|
1:81
|
1:62
|
1:50
|
1:33
|
1:25
|
1:15.6
|
1:8.3
|
|
50BYJ26-30
|
12
|
2
|
30
|
2-1-2
|
7.5/i
|
450
|
20
|
18
|
15
|
12
|
9.5
|
8
|
6.5
|
5
|
4
|
2.5
|
2
|
1.2
|
0.6
|
500V AC 1Min
|
E
|
|
50BYJ46-30
|
12
|
4
|
30
|
4-1-2
|
7.5/i
|
350
|
16
|
14
|
12
|
10
|
8
|
6
|
4.8
|
3.2
|
2.6
|
1.8
|
1.3
|
0.8
|
0.4
|
500V AC 1Min
|
E
|
|
50BYJ212-30
|
12
|
2
|
30
|
2-1-2
|
3.75/i
|
500
|
25
|
22
|
19
|
15
|
13
|
10.5
|
9
|
6.8
|
5.6
|
4.5
|
3.2
|
2.2
|
1.2
|
500V AC 1Min
|
E
|
|
50BYJ412-30
|
12
|
4
|
30
|
4-1-2
|
3.75/i
|
400
|
22
|
19
|
16
|
13
|
11
|
9
|
7.5
|
6
|
4.8
|
3.8
|
2.5
|
1.8
|
1
|
500V AC 1Min
|
E
|
|
|
